Briquetting Press More Information

Models Specifications (Performance Parameters)

Infinite Impact Briquetter Models

IB 125

IB-750

IB 1000

Input size of biomass (mm) *

<5

<7

<20

Machine Output (kg/h) **

100 - 225

550 - 850

1250 - 1750

Connected Loads (hp)

10.5

34.5

69

Main Motor

Oil Pump

Vertical Feeder

Conveyor

10

0.5

--

0

30

0.5+0.5****

2

2

60

0.5+0.5****

5

3

power consumption(kW)

6-8(max)

17-23(max)

37-49(max)

Displacement (m3/h)

2.71

7.64

13.45

Max Pressure (kg/cm2)

1500

1500

1500

Stroke (mm)

120

150

190

Speed (RPM)

300

270

180

Briquette Diameter ( mm)

35

60

90

Oil Cooling (Heat X area)

Crossflow heatx 0.34 m2 Area

Crossflow heatx 0.59 m2 Area

Crossflow heat x 1.2 m2 Area

Overall Dimensions(mm)

1000(I) x 400(W) x700(h)

1600(I) x 600(W) x 1150(h)

2000 (l) x 750 (w) x 1400 (h)


* Standby

Note As a result of continuous research and developments. the specifications and design features of the machine are subjects to changes from time to time.

Input Parameters

Biomass

Bulk Density

Moisture content

Biomass Size

160 kg/m3

< 12%

< 5mm

Cooling Water

Temperature

60 oC

Flow

10 lpm (Recirculated from water tank)

Lubricating Oil

Type

Perfecto 250

Briquette

Density

1050 kg/m3
